Control system: designed for monitoring and controlling the instrument via the computer.
Column Compartment/oven with superior thermal performance, multistage (20 ramps) programmed temperature control
function, (supported by “control system”)
Advanced built-in data acquisition system , supporting real time instrument status monitoring, detection signal acquisition
and PC control
Column oven supports quick heat-up and rapid cool-down with automated back-door opening.
Flexible sample introduction system: 2 sample injectors could be installed and operated simultaneously with independent
temperature control.
High sensibility and stability detector.
2 independent and analog signals output.
M6 software, compatible with GLP/FDA-21 CFR Parti1 requirements and regulations, (electronic records and signatures)
Electronic pneumatics control system
Flow rate: 200ml/min (N2), lOOOml/min (He)
Flow rate accuracy: ±5%
Flow rate repeatability: ±0.35%
Split ratio: 0-5000(He), 0-1000(lM2)
Inlet temperature: 0-420°C
Gas chromatography and accessories:
Carrier Gas System + Sample Introduction System + Separation System + Temperature Control System + Detector
Carrier Gas System: air source/ purification and desiccation device/ flow rate control device
Sample Introduction System: sample injector
Separation System: chromatographic column(packed column and capillary column)
Temperature Control System (Column Oven): constant temperature and programmed temperature
Detector: FID/ FPD/ NPD
Advanced Microcomputer Control System
Superior performance with advanced, microcomputer-based
temperature control system
High temperature accuracy (optimum ± 0.02°C), high reliability,
and anti-interference
Self-diagnosis/ self-protection function (overheat protection,
power-off protection, etc.)
Intuitive display of timing program, detector status,
measurement range, current setting, etc
